與Mac II(1987年3月)同時發布的Mac SE進一步解決了擴展問題。它出現在一個新的白金盒子裡，有一個擴展槽，裡面有一個海灣，要么是第二個內部軟碟機，要么是內部硬碟。Mac SE也是第一個包括蘋果桌面匯流排(ADB)的Mac電腦，它允許最多16個輸入設備。
基本介紹
- 中文名：Macintosh SE
- CPU：Motorola MC68000
- CPU Speed：8 MHz
- Bus Speed：8 MHz
Macintosh SE
Macintosh SE
CPU
Data Path: 16 bit
ROM: 256 kB
RAM Type: 30 pin SIMM
Minimum RAM Speed: 150 ns
Onboard RAM: 0 MB
RAM slots: 4
Maximum RAM: 4 MB
Expansion Slots: 1 SE PDS
Video
Monitor: 9″ built-in
Max Resolution: 1 bit 512x342
Storage
Hard Drive: optional 40 MB
Floppy Drive: 1 or 2 800 kB 3.25″
Input/Output
ADB: 2
Serial: 2
SCSI: DB-25
Audio Out: mono 8 bit mini
Speaker: mono
Miscellaneous
Codename: Mac ±, PlusPlus, Aladdin, Freeport, Maui, Chablis
Gestalt ID: 5
Power: 100 Watts
Dimensions: 13.6" H x 9.69" W x 10.9″ D
Weight: 17 lbs.
Minimum OS: System 3.0/Finder 5.1
Maximum OS: 7.5.5
Introduced: March 1987
Terminated: August 1989
Released at the same time as the Mac II, (March, 1987) the Mac SE further addressed the issue of expansion. It came in a new platinum case, had an expansion slot, and included a bay for either a second internal floppy drive, or an internal hard drive. The Mac SE was also one of the first Macs to include an Apple Desktop Bus (ADB), which allowed for up to 16 input devices. It sold for $2,898 for a dual floppy configuration. In August 1989, The SE was replaced by the SE FDHD. Thanks to Eric Rasmussen For OS info.
